Application:
Applicable for weighing of light or bulky products, such as large-sized nuts, vegetables, salads, etc.
Main Function & Features:
1. Professional digital weighing module with high precision and good stability
2. Control system: MCU or PLC (optional).
3. Touch screen interface with different levels of authorized access; up to 16 different languages for choice; application
software upgraded through USB.
4. Factory parameters recovery function; 99 preset product parameters to meet different parameter program requirements.
5. Weighing hopper able to discharge in turn to effectively prevent products from blocking.
6. Weighing and counting function to meet diverse needs from customers.
7. Real-time display of amplitude of each vibration pan as well as product weight in each hopper to better monitor the running
status of the machine.
8. Machine body with SUS304/316 for option and IP65 dust and waterproof design.
9. Cleaning function: able to make the hoppers in opening state for easy daily cleaning and maintenance.
10. Modular design of control system for easy maintenance and cost-saving
Technical Parameters:
| Model | TY-A-M14-3；TY-A-P14-3 |
| Max. Weighing (one hopper) | 100-5000g |
| Accuracy | x (0.5) |
| Min. Scale Interval | 0.1g |
| Max. Speed | 60 WPM |
| Hopper Volume | 5.0L |
| Control System | MCU / PLC |
| HMI | 7’’ / 10’’ color touch screen |
| Power Supply | AC220V/110V ±10% 50HZ/60HZ, 2KW |
| Packing Dimension | Machine: 1,530(L)*1,530(W)*1,658(H)mm
Spare parts: 1,480(L)*1,100(W)*1,238(H)mm |
| Package weight | Machine: 600kg
Spare parts: 330kg |
